Sharp-X1

Características

Teclado  	Full-stroke Teclado
CPU  	Sharp Z80 A
Velocidad  	4 MHz
RAM  	64 KB
VRAM  	4 KB (up to 48 KB)
ROM  	6 KB
Modos de Texto  	40 / 80 x 25
Modo gráfico  	320 x 200 / 640 x 200
Colores  	8
Sonido  	3 voices PSG
Puertos de entrada/salida  	2 x Puertos de entrada/salida, 2 x joysticks (Atari), audio out, Teclado, printer
Almacenamiento interno  	Tape
OS  	CP/M ?
Fuente de alimentación  	Built-in PSU
Precio  	155,000 yen (Japan)

Características

Teclado  	Full-stroke Teclado
CPU  	Sharp Z80 A
Velocidad  	4 MHz
RAM  	64 KB
VRAM  	48 KB
ROM  	6 KB
Modos de Texto  	40 / 80 x 25
Modo gráfico  	320 x 200 / 640 x 200
Colores  	8
Sonido  	3 voices PSG
Puertos de entrada/salida  	2 x joysticks (Atari), audio out, Teclado, printer
Almacenamiento interno  	Tape
Perifericos  	119,800 yen (Japan)

Características

Teclado  	Full-stroke Teclado
CPU  	Sharp Z80 A
Velocidad  	4 MHz
RAM  	64 KB
VRAM  	48 KB
ROM  	6 KB
Modos de Texto  	40 / 80 x 25
Modo gráfico  	320 x 200 / 640 x 200
Colores  	8
Sonido  	3 voices PSG
Puertos de entrada/salida  	2 x Puertos de entrada/salida, 2 x joysticks (Atari), audio out, Teclado, printer
Almacenamiento interno  	3 FDD (320 KB)
OS  	S-OS
Fuente de alimentación  	Built-in PSU
Precio  	198,000 yen (Japan, 1983)

Características

Teclado  	separated full-stroke Teclado with numeric keypad
CPU  	Sharp Z80 A
Velocidad  	4 MHz
RAM  	64 KB
VRAM  	96 KB
ROM  	128 KB + 40 KB
Modos de Texto  	20 / 40 / 80 x 10 / 12 / 20 / 25
Modo gráfico  	320 x 200 / 640 x 200 / 320 x 400 / 640 x 400
Colores  	8
Sonido  	3 voices PSG
Tamaño/Peso  	Main unit: 390(W) x 390(D) x 108(H) mm / 11 Kg
Teclado: 390(W) x 185(D) x 35(H) / 1.3 Kg
Puertos de entrada/salida  	2 x Puertos de entrada/salida, 2 x joysticks (Atari), audio out, Teclado, printer
Almacenamiento interno  	2 x 5.25 FDD
OS  	S-OS
Fuente de alimentación  	Built-in PSU
Precio  	Model 10: 168 000 yen (Japan, 1984)
Model 20: 248 000 yen (Japan, 1984)
Model 30: 278 000 yen (Japan, 1984)

Características

Teclado  	Full-stroke Teclado
CPU  	Sharp Z80 A
Velocidad  	4 MHz
RAM  	64 KB
VRAM  	48 KB
ROM  	6 KB
Modos de Texto  	40 / 80 x 25 (+ japanese Kanji characters)
Modo gráfico  	320 x 200 / 640 x 200
Colores  	8
Almacenamiento interno  	Tape
Precio  	139,800 yen (Japan, 1984)

Características

Teclado  	Full-stroke Teclado
CPU  	Sharp Z80 A
Velocidad  	4 MHz
RAM  	64 KB
VRAM  	48 KB
ROM  	6 KB
Modos de Texto  	40 / 80 x 25 (+ japanese Kanji characters)
Modo gráfico  	320 x 200 / 640 x 200
Colores  	8
Sonido  	3 voices PSG
Puertos de entrada/salida  	2 x Puertos de entrada/salida, 2 x joysticks (Atari), audio out, Teclado, printer
Almacenamiento interno  	Tape
Precio  	119,800 yen (Japan, 1984)

Características

Teclado  	Full-stroke Teclado, JIS standard
CPU  	Sharp Z80 A
Velocidad  	4 MHz
RAM  	64 KB
VRAM  	96 KB
ROM  	128 KB + 40 KB
Modos de Texto  	20 / 40 / 80 x 10 / 12 / 20 / 25
Modo gráfico  	320 x 200 / 640 x 200 / 320 x 400 / 640 x 400
Colores  	8
Almacenamiento interno  	2 x 5.25 disk-drives
Precio  	168 000 yen (Japan, 1986)

Características

Teclado  	Full-stroke Teclado, JIS standard
CPU  	Sharp Z80 A
Velocidad  	4 MHz
RAM  	64 KB (ZII & ZIII have 128 KB)
VRAM  	96 KB
ROM  	128 KB + 40 KB
Modos de Texto  	20 / 40 / 80 x 10 / 12 / 20 / 25
Modo gráfico  	320 x 200 / 320 x 192 / 320 x 400 / 640 x 192 / 640 x 200 / 640 x 400
Colores  	4096
Sonido  	3 voices PSG + 8 voices FM
Puertos de entrada/salida  	Two Puertos de entrada/salida, analog video out, disk drive expansion, video in/out, RS232c port, printer port, Teclado, 2 x joysticks (Atari standard), tape interface, digital Pantalla connector (8 Colores), audio out
Almacenamiento interno  	2 x 5.25 disk drive (2D,2DD and 2HD)
OS  	S-OS
Fuente de alimentación  	Built-in PSU
Precio  	218,000 yen (Japan, 1986)an, 1984)

Características

Teclado  	Full-stroke Teclado, JIS standard
CPU  	Sharp Z80 A
Velocidad  	4 MHz
RAM  	128 KB
VRAM  	96 KB
ROM  	128 KB + 40 KB
Modos de Texto  	20 / 40 / 80 x 10 / 12 / 20 / 25
Modo gráfico  	320 x 200 / 320 x 192 / 320 x 400 / 640 x 192 / 640 x 200 / 640 x 400
Colores  	4096
Sonido  	3 voices PSG + 8 voices FM
Puertos de entrada/salida  	Two Puertos de entrada/salida, analog video out, disk drive expansion, video in/out, RS232c port, printer port, Teclado, 2 x joysticks (Atari standard), audio out
Almacenamiento interno  	2 x 5.25 disk-drive (2D,2DD and 2HD)
OS  	S-OS
Fuente de alimentación  	Built-in PSU
Precio  	169 800 yen (Japan, 1988)

Historia

A Sharp X-1 computer with PC Engine built in, the same concept as say the Teradrive. Whole thing came as a set, with matching console, keyboard, and monitor. Sharp is known for taking videogame systems and combining them with other electronics, and have made Super Famicom televisions, Famicom televisions, and the Famicom tilter. This particular console was released in 1989 as the last of Sharps X series of computers. The user is able to toggle between the PC Engine and X-1 computer functionality but cant have them both on at the same time.
